Rear & Grille Light Control Units

Lighting for communication and individualization

Continental's Rear Light Controller addresses our customers' desire for individualization.

Light Solutions Product Portfolio

Overview Light Solutions

let there be light

Benefits & Features

Thanks to its many flexible connection options, it enables different lighting architecture concepts throughout the entire chassis area.

Cited applications are, for example, the supply and control of areas with a large number of individually controllable lighting elements, such as those required in rear and grille lighting.

The light modules can be supplied via several constant currents, voltage sources or high-side switches and controlled via UART-over-CAN or LIN.

  • Demand for Rear Light Control units driven by high pixel count RCLs, dynamic functions like welcome/goodbye, sequential turn, etc.
  • Potential hub for feature integration: power closures, lighting, wiper, etc.

Technical Information

  • Turn Indicator
  • POS, Stop Light
  • Fog Light
  • Reverse Light
  • Side Marker
  • Projection Light
  • Logo Light
  • Signature Light
  • 6 Constant Voltage Channels
  • 3 Constant Current Channels
  • 6 High-Side Switches
  • Power: 150W
  • Public High Speed CAN FD
  • 2x LINEN
  • 3x UART Over CAN (LMM control)
  • Dimensions: 119 x 109 x 33.8 mm (without attachment points)
  • Weight: 247g
